GENERAL SPECIFICATIONS

• Display:
  • 17” TFT LCD panel
  • Resolution: 1280 x 1024
  • Viewing Area: 377.920mm (H) x 270.336mm (V)
  • Contrast Ratio: 500:1
  • Brightness: 300 nits
  • Response time: 6 ms (Raising) / 2 ms (Falling)
  • View Angle: 80/80/80/80 degree (U/D/L/R)
  • Tilt Angle: 15° to 70°
• Touch Panel:
  • 5-wire Resistive
• I/O Ports:
  • Touch Interface: USB
  • 2 Pass through USB port for Optional MSR/RFID & Rear display Attachments
• Input Signal: VGA
• Audio: N/A
• OS Support: Windows XP Pro / POSReady 2009 / Windows 7 / POSReady 7 / WIN8.1 Embedded Retail Industry
• Environmental Sealing: N/A
• Operating Environment:
  • Temperature: 0 ~ +40 °C
  • Humidity: 20 ~ 90% RH
• Storage Environment:
  • Temperature: -20 ~ +70 °C
  • Humidity: 10 ~ 90% RH
• Power Supply: 12V DC Power Adapter (50W)
• External Dimensions (WxDxH): 401mm x 385mm x 286mm
• Weight: 6.82 Kg
• EMC/Safety Standards: C-Tick, CE
