Printing Method |
Line thermal printing
|
Printing Width |
80mm Paper 72mm
58mm Paper 54mm
|
Dot Pitch |
Dot PitchGCUBE102: 203 dpi
GCUBE100: 180 dpi (Special Order)
|
Printing Speed (Max.) |
Max. 250 mm/sec on 80 mm Mono Paper
Max. 150 mm/sec on 58 mm Mono Paper
Max. 100 mm/sec on Two Colour Paper
|
Number of Columns |
On 80mm paper
Font A : 48 (Gcube-102), 42 (Gcube-100),
Font B : 64 (Gcube-102), 56 (Gcube-100),
|
Character Size |
Font A:42/21
Font B:56/28
|
Character Table/Code Pages |
N/A
|
Bar-code Type |
UPC-A, UPC-E, EAN8, EAN13, Code 39, Code 93, Code 128, ITF, CODABAR, PDF417, QR Code
|
Line Spacing |
N/A
|
Paper feed method |
Friction
|
Paper Type |
Thermal Paper Roll
|
Paper Width |
80+0/-1 mm, 58 mm+0/-1
|
Paper Roll Diameter |
Max Ø 83.0mm
|
Paper Thickness |
0.06 – 0.08mm
|
Paper Supply Method |
Easy Paper Loading either from top or front, Drop in and Print
|
Auto Cutter |
Guillotine Type
|
Indicators/Controls |
Power light, LED for operation codes, Feed Button, on/off Switch
|
Emulation |
ESC/POS
Star
|
Print Buffer |
64KB
|
NV Memory |
8Mbyte Data Memory
|
Sensors |
Paper end Sensor
Printer Cover open Sensor
|
Drawer Port |
1 port (opens 2 drawers, special cable is needed to open 2 drawers)
|
External Device Port |
N/A
|
Interfaces |
USB, RS232 & Ethernet
USB, RS232 & Parallel (Special Order)
USB, Ethernet & Wifi
USB, Ethernet & Bluetooth
|
Driver available |
Windows driver, OPOS, JPOS (Linux & Mac), Cups driver (Linux & Mac)
|
Software Utilities |
Utility Program
|
Power Supply |
External AC Adapter
Rated input: AC 90 to 264 V, 50/60 Hz
Rated output: DC24 V, 2.5 A
|
External Dimensions (WxDxH) |
123w × 123d × 123h mm
|
Weight |
0.75 Kg
|
Operating Environment |
5-45°C, 10-90% RH
|
Storage Environment |
-10-50°C, 10-90% RH
|
Reliability |
Mechanism: 70Mil Lines
Thermal Print head: 150Km
Auto Cutter: 1.5 Mil cuts
|
EMC/Safety Standards |
FCC class A, CE marking, TUV/GS, CE, CB, cTUVus
|
